Weber SUMMIT 400 - Page 11

11
MAINTENANCE
10. Unlatch the Spider Stopper Guards and remove.
Figure 11.
Figure 11
Manifold
11. Pull the manifold out of the burners. Figure 12.
Figure 12
9. Disconnect white and black wire from each igniter.
Figure 10.
Figure 10
Black wire
White wire
Summit 400
Summit 400
Manifold
