Weber Summit Gold D LP - Assembly Instructions; Frame and Base Assembly

B-a
1
Ba401.c
a
b
c
(1)
(2)
(3)
(3)
 CAUTION: Before
proceeding to the next
step check that frame rail
(2) is on the side with the
swing tables (3). The tab
on frame rail (2) must be
facing toward the wheels.
Place corregated
from each side of
the Cookbox under
the Caster and
Wheel Frame
Assembly to level
the frames for
Frame Rail
Assembly.
