Mounting the LINK 640
The LINK 640 can be attached with the two adhesive strips or the two tapping screws.
You can attach the holder to the top or to the bottom side of the LINK 640.
Attaching the holder using the adhesive strip
You can use the adhesive strip to fix the LINK 640 to your vehicle. Follow the safety instructions in this
document.
1. Choose a flat surface for accurate positioning of the unit.
Remember, when the LINK 640 is in the holder, it must not be obstructed by metal objects.
2. Clean the surface with the supplied cleaning tissue, so that the surface is oil free, dry and clean.
3. Remove the protective film from one side of the strip.
4. Stick the strip to the bottom side of the holder as shown below.
Important: Use the strip only in combination with the holder. Do NOT place the strip on the serial num-
ber sticker of the device.
5. Remove the protective film from the other side of the strip.
6. Place the holder with the adhesive strip on the prepared surface. Press it gently for a few seconds until it
sticks.
Note: The full strength of the strip will be reached after approximately 72 hours depending on the
temperature.
7. Insert the LINK 640 into the holder. Press gently until it clicks into place.
13
