5 PE power supply for external capacitive CAN sensors:
For Webfleet Solutions accessories only. Please contact
Webfleet Solutions Customer Support.
CAN3 is equipped with a switchable 120 Ohm load
resistor.
CAN2 Low speed CAN port can be used alternatively as
dedicated 5V output port for contactless CAN sensor
support.
CAN1H, CAN1L, High speed CAN
CAN2H, CAN2L, High speed CAN*
CAN2HLS, CAN2LLS, Low speed CAN*
CAN3H, CAN3L, High speed CAN
* Only one of the CAN2 ports can be used.
USB A Mini USB connector for service functionality, for
example software update.
The USB interface is from USB device type. Powering the
device over USB for service reasons is possible without
GPRS modem functionality.
LEDs Green LED indicates the system status
Yellow LED indicates the connection status
Primary battery 3 V non-rechargeable, this device cannot be operated
with this battery
