Testing operation
In addition to the tests described below you can also test the operation of your LINK
710 using the LINK Toolkit app.
Power or Ignition test
Before testing the connection to power and to the ignition make sure you have
properly carried out the installation.
1. Check all connections to your LINK 710 device (wires, fuses etc.).
2. Turn off the ignition.
The green LED should be off and then go on every 3 seconds.
3. Turn on the ignition.
The green LED should be on and then go off every 3 seconds. If the device is
already activated, the green LED should be on all the time.
If the LED does not perform as described, monitor the LEDs for diagnostics .
Mobile network reception test
For this test, you may need to move the vehicle to a location with a clear view of the
sky, to make sure that you have adequate GPS and mobile network reception.
For this test put your LINK 710 device in the position where you want to fix it.
1. Turn on the ignition.
2. Look at the yellow LED. It should be on and then go off every 3 seconds.
As soon as the device has established a connection to WEBFLEET the yellow LED
stays on all the time.
If the LED keeps flashing for longer than 10 minutes, monitor the LEDs for
diagnostics .
