WECON VM AC Drive User Manual V2.0
WECON technology Co., Ltd
- 28 -
Code
Name
Range
Default
Feature
RAM
address
FD.50
Inner PLC Running
Option
LED Tens Place : Time Unit
0: Sec
1: Min
2: H
LED Thousands Place:
Starting Option
0: Start from stage 1
1: Start from the stage
when being stopped
2: Start with the rest period
at the stage being stopped
0
○
0D32
FD.51
Multi-Stage Speed 0
Source
0: FD.00
1: AI1
2: Reserved
3: Keypad Potentiometer
4: Reserved
5: PID
6: Reserved
0
○
0D33
FD.52
Multi-Stage Speed
Priority
0: Invalid
1: Valid
1
○
0D34
FE.00
Lock Option of
Parameters and
Buttons
0: Unlocked
1: Parameters Locked
2: Parameters & Keypad
Buttons Locked (Except
RUN/STOP/JOG)
3: Parameters & All Keypad
Buttons Locked
0
○
0E00
FE.01
User Password
0 to 9999
0
○
0E01
Table 5-1 Functional parameter
5.2 Monitoring Parameters
Parameter
Name
Minimum Unit
Priority
Address
D0.00
Running Frequency(Hz)
0.01Hz
◎
D000
D0.01
Set Frequency(Hz)
0.01Hz
◎
D001
D0.02
Bus Voltage(V)
0.1V
◎
D002
D0.03
Output Voltage(V)
1V
◎
D003
D0.04
Output Current(A)
0.01A
◎
D004
D0.05
IGBT Module Temperature(℃)
0.1℃
◎
D005
D0.06
DI Input Status
1
◎
D006
D0.07
DO Output Status
1
◎
D007
D0.08
Keypad Knob Voltage
0.01V
◎
D008
D0.09
AI Voltage(V)
0.01V
◎
D009
D0.10
Reserved
1
◎
D010
D0.13
PLC Stage
1
◎
D013
D0.14
Feedback Speed(Unit0.1Hz)
0.1Hz
◎
D014
Table 5-2 Monitoring Parameters
