WECON VM AC Drive User Manual V2.0
WECON technology Co., Ltd
2 Product information
2.1 Technical specifications
120% Rated Current: 1 min；150% Rated Current: 10 secs
Normal use below 1000m, derating 1% for every 100m rise above
1000m, up to 3000m
-10℃ ~ ＋50℃ ( IF the ambient temperature is between 40°C and
50°C, please use with derating)
Table 2-1 Technical specifications
2.2 Product nameplate
Figure 2-1 Product nameplate
2.3 Model description
VM – 2 S 1R5GB
1
② ③ ④
Power phase identification
S: single; T: three-phase
1R5-1.5kW, R is the decimal point
Table 2-2 VM series model
