3. Orient the Bottom Crossbar (10) so that the warn-
ing decal is on top. Attach the Bottom Crossbar to
one of the Upright Bases (2) with two M8 x 77mm
Bolts (28), a Support Plate (13), and two M8
Locknuts (22). Do not tighten the Locknuts yet.
Attach the Bottom Crossbar (10) to the other
Upright Base (2) in the same way.
2
2
Hexagonal
h
oles on
this side
2. Attach an Upright Base (2) to one of the
Stabilizers (1) with the indicated two M8 x 68mm
Carriage Bolts (20) and two M8 Locknuts (22).
N
ote: Attach the Upright Base so that the
hexagonal holes are on the indicated side. Do
n
ot tighten the Locknuts yet.
Attach the other Upright Base (not shown) to
the other Stabilizer (not shown) in the same
way.
28
2
10
2
13
22
Decal
3
