7
2. Slide the two Weight Bumpers (25) onto the
Weight Guides (4), and insert the Weight
Guides into the Short Base (6).
A
ttach the Weight Guides (4) to the Short Base
(6) with two M10 x 25mm Screws (60) and two
M10 Washers (73).
2
4
6
60
25
73
73
25
3
4
15
15
Pin Hole
3. Orient the nine Weights (15) so that the pin
holes are on the bottom of the Weights as
shown.
Slide the Weights (15) onto the Weight Guides
(4).
