5
This chart is provided to help you identify the small parts required for assembly. The number in parentheses
below each part refers to the key number of the part from the PART LIST near the end of this manual. Note: If a
part is not in the hardware kit, check to see if it has been preattached. To avoid damaging parts, do not
use power tools for assembly.
PART IDENTIFICATION CHART
M10 Curved
Washer (37)
M10 Washer (23)
M6.5 Curved
Washer (36)
M6 Washer
(31)
M8 Curved
Washer (44)
M8 x 60mm Screw (41)
M10 Locknut
(35)
M10 x 55mm Button Screw (45)
M4 x 16mm
Self-tapping
Screw (33)
M4 x 30mm Self-tapping
Screw (42)
M8 x 20mm
Screw (39)
M10 x 55mm Bolt (40)
M10 x 105mm Bolt (16)
M10 x 95mm Bolt (32)
M10 x 85mm Bolt (30)
M10 x 65mm Screw (38)
M6 x 35mm Screw (43)
M6 x 65mm Screw (34)
