10
7. Slide the two Weight Bumpers (27) onto the
Weight Guides (21).
Orient nine Weights (22) so that the pin holes
(A) are on the bottom as shown. Slide the
Weights onto the Weight Guides (21).
Insert the Weight Selector (24) into the nine
Weights (22). Make sure that the pin (B) on the
Weight Selector is oriented as shown.
Using a plastic bag to keep your fingers clean,
apply some of the included grease inside
the indicated holes in the remaining Weight
(22). Then, slide the Weight onto the Weight
Guides (21).
6
7
21
6. Attach the Seat Tube (6) to the Upright (3) with
two M8 x 65mm Bolts (68), two M8 Washers
(59), and two M8 Locknuts (58); do not tighten
the Locknuts yet.
Attach the Seat Tube (6) to the Front Leg (7)
in the same way.
7
6
3
58
59
68
68
68
68
59
58
27
22
22
24
B
A
Grease
