M6 Washer
(82)
M8 Locknut (58)
M6 Locknut (78)
M8 Washer (59)
M10 Locknut (56)
M4 Washer
(33)
M10 x 70mm Bolt (86)
M10 x 46mm Bolt (81)
M10 x 63mm Bolt (75)
M10 x 67mm Bolt (71)
M10 x 85mm Bolt (67)
M10 x 25mm
Button Bolt (77)
M10 x 155mm Bolt (74)
M8 x 65mm Bolt (68)
M8 x 22mm
Shoulder Bolt (65)
M6 x 63mm Screw (70)
M6 x 16mm
Screw (62)
M4 x 20mm Self-
tapping Screw (69)
M10 x 77mm Bolt (79)
M10 x 51mm Bolt (66)
M10 Washer (57)
M5 x 20mm Self-
tapping Screw (64)
M12 Nut (84)
Large Washer (85)
M8 x 63mm Carriage Bolt (87)
Refer to the drawings below to identify small parts used in assembly. The number in parentheses by each draw-
ing is the key number of the part, from the PART LIST near the end of this manual. Note: Some small parts
may have been preattached. If a part is not in the hardware kit, check to see if it has been preattached.
PART IDENTIFICATION CHART
5
To Next Page
