PART LISTmModel No. 831.159360 Ros96A
Key Part Key Part
No. No. Qty. Description No. No. Qty.
1 100291 4 5/16" x 2 1/2" Carriage Bolt 49 120733 6
2 012139 4 1/4" Nylon Locknut 50 132812 3
3 012056 22 5/16" Nylon Locknut 51 132816 1
4 132796 1 Front Base 52 116868 1
5 132797 1 Stabilizer 53 103087 2
6 115164 4 "V"-Pulley 54 127061 1
7 013581 3 3/8" x 2 1/2" Bolt 55 132817 1
8 014073 11 5/16" Flat Washer 56 132822 1
9 014132 7 3/8" Flat Washer 57 132883 1
10 014063 10 1/4" Flat Washer 58 132821 1
11 119377 7 5/16" x 2 3/4" Bolt 59 128292 1
12 013601 3 3/8" x 2" Bolt 60 128293 1
13 132798 2 Seat 61 131516 2
14 123385 2 5/16" x 2 3/4" Carriage Bolt 62 132887 2
15 115370 13 3 1/2" Pulley 63 132818 1
16 120003 2 3/8" x 3 1/2" Bolt 64 122691 1
17 132799 1 Press Frame 65 120696 1
18 123148 4 1/4" x 1/2" Screw 66 132819 8
19 115644 2 Weight Bumper 67 132820 1
20 132800 1 Pulley Bracket 68 128297 1
21 012149 20 3/8" Nylon Locknut 69 108778 4
22 127948 6 5/16" x 2 1/2" Bolt 70 120808 4
23 132801 1 Medium Cable 71 118471 5
24 128276 1 1/4" x 2" Screw 72 102073 1
25 120294 8 Weight 73 121845 1
26 122693 1 Weight Pin 74 126891 2
27 108874 6 2" Square Inner Cap 75 126808 2
28 127065 2 Pad Tu be 76 126866 1
29 132802 1 Leg Lever 77 132885 1
30 103805 4 Foam Pad 78 120822 2
31 119702 6 Hand Grip 79 132884 1
32 103833 2 1 1/2" Square Inner Cap 80 132886 1
33 121421 1 5/16" x 2 1/4" Bolt 81 132815 2
34 119170 4 3/4" Round Inner Cap 82 130688 1
35 129051 1 5/16" x 2" Eyebolt 83 127231 2
36 132803 1 Front Seat Frame 84 126892 2
37 132804 2 Seat Plate 85 120354 2
38 121567 1 1/4" x 2 1/4" Carriage Bolt 86 132814 1
39 115177 1 Nylon Strap 87 013399 4
40 119192 2 Seat Knob 88 124590 1
41 132805 1 Large Backrest 89 013141 1
42 132806 1 Front Upright 90 122950 1
43 128283 4 1/4" x 2 1/2" Screw 91 121567 1
44 113666 7 1 3/4" Square Inner Cap 92 132813 2
45 120596 2 10" Pad 93 126145 1
46 132807 2 Press Arm 94 127234 2
47 132809 1 Left Arm # 132823 1
48 132811 1 Right Arm # 125056 1
Description
1" Round Inner Cap
Long Cable Trap
Rear Base
Chain
Cable Clip
Lat Bar
Top Frame
Rear Upright
Long "U"-Bracket
Short Cable
3/8" x 8" Bolt
5/16"x 6" Bolt
1/2" x 3/4" Spacer
Weight Guide
Weight Tube
Weight Tube Bumper
1" Square Inner Cap
Cable Trap
Small "U"-Bracket
5/16"x 5" Bolt
1" Retainer
1" Round Cover Cap
3/8" x 3 3/4" Bolt
5/16"x 1 3/4" Bolt
5/8" x 9/16" Spacer
1 1/8" x 2 1/2" Plastic Bushing
1" x 7/8" Plastic Bushing
Top Weight
Rear Seat Frame
2" Square Cover Cap
Squat Arm
Small Backrest
"r' Plate
1/4" x 2 1/4" Screw
1" x 2" Inner Cap
5/16" Nylon Jam Nut
3/8" x 3 1/4" Bolt
Long Cable
3/8" x 1 3/4" Bolt
3 1/2" Low Pulley
#8 x 1/2" Tap Screw
Rubber Bumper
1/4" x 2 1/2" Carriage Bolt
Handle
5/16" x 3" Bolt
1/2" x 17/32" Spacer
User's Manual
Exercise Poster
Note: "#" indicates a non-illustrated part. Specifications are subject to change without notice.
