WeiderPro Pro 4500 - Page 21

21
32. Attach the Seat (15) to the Seat Frame (6) with
t
wo M6 x 80mm Screws (70) and two M6
Washers (82).
32
15
82
70
6
33. Insert the Pad Tube (29) into the Front Leg (7).
Slide two Small Foam Pads (28) onto the Pad
Tube. Then, press two Pad Caps (34) onto the
Pad Tube.
Slide two Small Foam Pads (28) onto the Leg
Lever (8). Press two Pad Caps (34) onto the
Leg Lever.
33
29
8
28
7
34
34
28
34
28
