WeiderPro Pro 4500 - LOCKING THE WEIGHT STACK

24
5
10
9
21
89
88
ARM CONVERSION
To use the Arms (9, 10) as butterfly arms, insert the
A
rm Pins (40) into the holes in the Upright (3) and
the Pivot Frame (5) as shown.
To use the Arms (9, 10) as press arms, insert the
A
rm Pins (40) into the holes in the Pivot Frame (5)
and the Arms.
40
3
Holes
LOCKING THE WEIGHT STACK
Lock the weight stack by inserting the Lock Pin (89)
through a Weight Guide (21) and securing the Lock
(88) onto the Lock Pin.
13
61
14
7
30
USING THE CURL PAD
To use the Curl Pad (14), remove the 64mm Round
Inner Cap (30) from the Front Leg (7). Insert the
Curl Post (13) into the Front Leg and secure it in
place with the Curl Knob (61).
When performing an exercise that does not require
the Curl Pad (14), remove the Curl Pad and insert
the 64mm Round Inner Cap (30) into the Front Leg
(7). Store the Curl Pad away from the weight sys-
tem.
