Weidmüller UC20-SL2000-EC-CAN User Manual

12 2604080000/03/08.2020Manual u-control
3 Systemoverview | General technical data
3.2 General technical data
Type of connection
"PUSH IN" solid, ne-wired
Wire cross-section 0.14 ... 1.5mm
2
(AWG 16 – 26)
Configuration interface
USB 2.0
Dimensions
Height 120.0 mm / 4.72"
(with release lever: 128.0 mm / 5.04")
Width 52.0mm / 2.05"
Depth 76.0 mm / 2.99"
Protection class (IEC 60529)
IP20
FlammabilityratingUL94
V-0
Temperature data
Operation (horizontal installation) for 24VDC +20%/-15%
-20°C to +55°C (2×5A power supply)
Operation (vertical installation) at 24VDC +20%/-15%
-20°C to +50°C (2×5A power supply)
Storage, transport -40°C to +85°C
Humidity
Operations 95%, non-condensing according to IEC 61131-2
Storage, transport 95%, non-condensing according to IEC 61131-2
Air pressure
Operations ≥ 795 hPa (altitude ≤ 2000 m) according to IEC 61131-2
Storage, transport ≥ 700 hPa (altitude ≤ 3000 m) according to IEC 61131-2
Vibration resistance
5 Hz ≤ f ≤ 8.4 Hz: 3.5 mm amplitude as per IEC 60068-2-6
8.4 Hz ≤ f ≤ 150 Hz: 1 g acceleration as per IEC 60068-2-6
Shock resistance
15g over 11ms, half sine wave, as per IEC 60068-2-27
Potential isolation
Test voltage max. 28.8V inside a channel
500VDC eld/system (according to EN60079-15:2010)
Pollution degree 2 (according to DINEN60664-1:2008)
Overvoltage category II (according to DINEN50178)
Approvals and standards
cULus UL61010
Maritime und offshore applications pending
EX zone 2 ATEX Directive 2014/34/EU
EMC IEC 61000 (partial standards according to the requirements of IEC
61131-2)
Explosion protection IEC60079-0:2012, IEC60079-15:2010, EN60079-0:2012,
EN60079-15:2010
PLC IEC61131-2
You can nd all product-specic technical data in the corresponding product description in Chapter5.
