4.8 Calculation of power loss
The power loss of the controller is calculated as follows:
P
controller
= P
0
+N
*
P
mod
+ I
in
*
ΔU
in
+ I
out
*
ΔU
out
P
0
Static power loss in the controller 24V
*
I
SYS
I
SYS
Current consumption from the system current
path
See table "Cur-
rent demand" in
section4.6
N Number of modules
P
mod
Power loss due to module supply from the
system current path
0.02 W
I
in
Current fed in through the input current path
ΔU
in
Voltage drop across the contacts in the input
current path
0.18 V
I
out
Current fed in through the output current path
ΔU
out
Voltage drop across the contacts in the output
current path
0.18 V
The power loss of a u-control station is calculated using
the power loss of the controller and the power loss of the
individual modules. It depends on the current in both current
paths. It is assumed that there is a maximum power loss
(P
module
) of 2watts for the modules.
P
station
= P
controller
+ N
*
P
module
Maximum values were assumed for these calculations. If you
need detailed calculations, please contact the Weidmüller
Service.
Calculation of power loss for the use in a potentially explo-
sive atmosphere
You will nd the module specic data needed for calculation
in the document "WI13ATEX0002_Power_Calc.pdf" which
you can download from the Weidmüller website.
4.9 Feedback energy in DO modules
With digital output modules, power is fed back through the
channels when inductive loads are switched off. The respec-
tive permissible breaking energy is noted in the technical
data of the DO modules. Depending on the switching fre-
quency the breaking energy leads to additional energy loss
in the output module.
Observe the specications in the Remote-I/O-
System u-remote Manual.
All manuals are available to download from the
Weidmüller website.
If the maximum permissible output power loss of a module
is exceeded, the module shuts down temporarily.
Feedback energy can be prevented by installing
external free-wheeling protection. With it, the
same switching rate can be achieved with an in-
ductive load as with a resistive load.
