WeighPack Systems PRIMO COMBI - MECHANICAL COMPONENTS OVERVIEW; Machine Overview and Parts

8
January, 2017
MACHINE OVERVIEW
MECHANICAL ASSEMBLIES
ITEM
DESCRIPTION
ITEM
DESCRIPTION
1
HOPPER
7
BASE FRAME
2
CENTER CONE
8
H.M.I. TOUCH SCREEN
3
LINEAR FEED PAN
9
STEP MOTOR LOAD CELL
4
FEED BUCKET
10
LINEAR VIBRATOR
5
WEIGH BUCKET
11
CENTER CONE VIBRATOR/MOTOR
6
DISCHARGE CHUTE
