Weinmann prisma20C User Manual

88 EN WM 100 TD
WM 67841c 03/2015
12 Appendix
Peak flow as per ISO 80601-2-70
CPAP and APAP mode
Test pressures:
4hPa
8hPa
12 hPa
16 hPa
20 hPa
AcSV mode, BiLevel
Test pressures:
4hPa
10.5 hPa
17 hPa
23.5 hPa
25 hPa
30.0 hPa
Pressure measured at the
patient connection opening
with a flow of 40 l/min
4.0 hPa
8.0 hPa
11.9 hPa
15.9 hPa
19.9 hPa
4.0 hPa
10.4 hPa
17.0 hPa
23.5 hPa
25 hPa
30.0 hPa
Average flow at the patient
connection opening
235 l/min
230 l/min
220 l/min
215 l/min
210 l/min
235 l/min
225 l/min
215 l/min
200 l/min
195 l/min
190 l/min
Warming of respiratory air Max. +3°C
Stability of the dynamic pressure (short-term
accuracy) for 10 breaths/min as per ISO 17510-
1:2007 when using the 19 mm hose.
7hPa
10 hPa
13.5 hPa
20 hPa
Stability of the dynamic pressure (short-term
accuracy) for 15 breaths/min as per ISO 17510-
1:2007 when using the 19 mm hose.
7hPa
10 hPa
13.5 hPa
20 hPa
Stability of the dynamic pressure (short-term
accuracy) for 20 breaths/min as per ISO 17510-
1:2007 when using the 19 mm hose.
7hPa
10 hPa
13.5 hPa
20 hPa
Δp<0.24 hPa
Δp<0.28 hPa
Δp<0.3 hPa
Δp<0.4 hPa
Δp<0.24 hPa
Δp<0.32 hPa
Δp<0.4 hPa
Δp<0.48 hPa
Δp<0.4 hPa
Δp<0.32 hPa
Δp<0.46 hPa
Δp<0.56 hPa
Specification Therapy device
