Installation and operating instruction

Gas burner WG20…/1-C LN

7 Commissioning

83240802 1/2020-01 La

37-96

Full load

[kW]

Setting pressure

into gas butterfly

valve

[mbar]

Min. connection pressure into isolating

valve

[mbar] (low pressure supply)

Nominal diameter valve train ¾" 1" 1"

Multifunction assembly W-MF SLE 507 507 512

Liquid Petroleum Gas: Hi = 25.89 kWh/m

, d = 1.555

The selection is calculated for Propane, it can however, also be used

for Butane.

80 9.0 13 – –

90 9.6 13 – –

100 10.1 13 – –

110 10.6 14 – –

120 11.0 14 – –

130 11.3 14 – –

140 11.6 14 – –

150 12.0 15 – –

160 12.3 15 – –

170 12.5 16 – –

180 12.6 17 – –

190 13.7 18 – –

200 14.8 19 – –
