WEISS
Installation- and operating manual Handling device HP140T R09-2011
33/52
Installation
5.5 Weiss Tool-Connector
5
5.5 Weiss Tool-Connector
5.5.1 Adaption gripper on front side
Fig. 17: Gripper front side
5.5.2 Adaption gripper left
Fig. 18: Gripper left
