REFLEX SUMMARY
dB
100   x -
90  x  
80 x   
70 x  x x
Hz 500 1k 2k 4k
Press ◄ to return and view the tympanogram, reflex results or to repeat the test. When satisfied
with the results press ►.
The message “Saving as last test” will be displayed briefly and the results will be saved in the “last
test” memory. The results will remain available until a new test is started, even if the MicroTymp
4 is turned off.
If both ears were chosen for test the entire sequence will now be repeated for the right ear:
TESTING RIGHT EAR
INSERT PROBE
Cancel Skip
Press ► to skip testing of the right ear and view results for the left ear. Press ◄ to return to the
main menu.
When the selected ears have been tested and the results saved the PROCESS RESULTS menu will
be displayed. This accesses the following functions:
