AT-2plus User Guide Spirometry Supplement Page 43
Art. No. 2. 510339wa ©1999
AT-2plus User Guide Spirometry Supplement Page 43
Art. No. 2. 510339wa ©1999
Changing the Flow Sensor SP-250 (RS-232)
WARNING
THE DISPOSABLE MOUTHPIECE IS DESIGNED FOR ONE-TIME USE TO
ELIMINATE THE DANGER OF CROSS CONTAMINATION - DO NOT USE THE
MOUTHPIECE FOR MORE THAN ONE PATIENT.
1. Remove disposable mouthpiece (1) by gently but firmly pulling it away from the handle (2).
2. Discard the complete assembly.
3. Position new disposable mouthpiece (Part No. 2.100077) and gently but firmly click it in position.
NOTE: The disposable mouthpiece can only be positioned in one direction and no force is necessary to
insert it on the handle. Ensure that the orientation is correct by checking the guide protrusion in
sensor against the guide slot in the handle.
4. Calibrate the sensor and unit as detailed on page 23.
Changing the Flow Sensor SP-250 (RS-232)
WARNING
THE DISPOSABLE MOUTHPIECE IS DESIGNED FOR ONE-TIME USE TO
ELIMINATE THE DANGER OF CROSS CONTAMINATION - DO NOT USE THE
MOUTHPIECE FOR MORE THAN ONE PATIENT.
1. Remove disposable mouthpiece (1) by gently but firmly pulling it away from the handle (2).
2. Discard the complete assembly.
3. Position new disposable mouthpiece (Part No. 2.100077) and gently but firmly click it in position.
NOTE: The disposable mouthpiece can only be positioned in one direction and no force is necessary to
insert it on the handle. Ensure that the orientation is correct by checking the guide protrusion in
sensor against the guide slot in the handle.
4. Calibrate the sensor and unit as detailed on page 23.
