WeldKing COOLTIG220 - Page 15

Manual no. WDT90100 Page 12
CoolTig - 220
CoolTig220 (208/230v input)
Figure 4.2
Power cord
C
y
linde
r
Gauge
Earth clamp
TIG torch MUST
CONNECTED TO
THE NEGATIVE WHEN
USE HF START!
Work
p
iece
Control cable
To main power
To gas regulator
Gas hose
