WeldKing COOLTIG220 - Section 4 Installations; TIG(AC;DC) Welding Connection Diagram

Manual no. WDT90100 Page 11
CoolTig - 220
SECTION4 INSTALLATIONS
4-1. TIG(AC/DC) welding connection diagram
CoolTig220 (115v input)
Figure 4.1
C
y
linde
r
Gauge
Control cable
Gas hose
Earth clamp
TIG torch MUST
CONNECTED TO
THE NEGATIVE WHEN
USE HF START!
Work
p
iece
To main power
To gas regulator
To 115 volt, 20 ampere
individual branch circuit
