WeldKing COOLTIG220 - Extension Welding Cable Selection Chart

Manual no. WDT90100 Page 17
CoolTig - 220
4-6. Extension Welding Cable Selection Chart
CAUTION! Use shortest cable possible. Turn off power before
connecting to weld output terminals!
Welding cable size in
AWG (mm
2
)
Maximum total cable (Copper) length in weld circuit
allowed in Ft(M)
Welding Amperes (A)
100 200
6(13) 260(80) 130(40)
4(20) 330(100) 160(50)
3(30) 410(125) 200(60)
Table 4.2
