WeldKing COOLTIG220 - Page 22

Manual no. WDT90100 Page 19
CoolTig - 220
14.12 pin control port
15. Negative output connect to torch
16. Gas outlet to torch
17. Gas inlet
18. Main switch
19. Power cord
20. Positive output connect
Figure 5.2
17
18
14
20
16
19
15
