WeldKing COOLTIG220 - Page 42

Manual no. WDT90100 Page 39
CoolTig - 220
29 7.411.250 rectifier BR6010(32*32) 1
30 7.253.013
solenoid valve 2/2
way
Model:YG2T-2 work
pressure:0~0.8MPa
power:DC24V(gas inletφ6)
1
31 8.123RM.923
solenoid valve
mounting case
Enhanced nylon 1
32 7.321.351 Hull amp sensor
BLY2-200IOV2L(BYD)
1
A-1
W.496RM.501-
C
TIG 200ACDC PFC
primary inverter PCB
Base board: B.067RM.501-C 1
A-2 8.713.184 insulation block polycarbonate 3 holes 12.5mm 19
A-3 7.425.670
single transistor
IGBT module
FGA180N33ATD 7
A-4 8.423RM.092 MUR sink(3)
TIG 200E AC/DC
S.006RM.515,section plate
7.800.014
1
A-5 8.422RM.247 heat sink(5)
TIG 200E AC/DC
S.006RM.515,section plate
7.800.014
1
A-6 8.123RM.929-A Middle plate
Made from 8.123RM.929,
enhanced nylon. Used with
S.006RM.561-E
1
A-7 8.422RM.248 heat sink(6)
TIG 200E AC/DC
S.006RM.515,section plate
7.800.014
1
A-8 8.422RM.249 heat sink(7)
TIG 200E AC/DC
S.006RM.515,section plate
7.800.014
1
A-9 8.422RM.250 heat sink(8)
TIG 200E AC/DC
S.006RM.515,section plate
7.800.014
1
