Wen 3720 User Manual

19
EXPLODED VIEW & PARTS LIST
Item# Stock # Description
1 3720-001 Table
2 3720-002 Table indicator
3 3720-003 Screw
4 3720-004 Guide wheel
5 3720-005 Screw
6 3720-006 Nylon nut
7 3720-007 Washer
8 3720-008 Extension rod holder
9 3720-009 Screw
10 3720-010 Locking piece
13 3720-013 Rear locking link
14 3720-014 Table extension lock lever
15 3720-015 Carriage bolt
16 3720-016 End cap
17 3720-017 Front rail
18 3720-018 Screw
18-1 3720-018-1 Washer
19 3720-019 Scale
20 3720-020 End cap
21 3720-021 Extension rail mount
22 3720-022 Washer
23 3720-023 Screw
24 3720-024 Extension table
25 3720-025 Alignment disc
26 3720-026 Screw
27 3720-027 Table insert
27-1 3720-027-1 Dado insert
28 3720-028 Compression spring
29 3720-029 Linkage pivot
30 3720-030 End cap
31 3720-031 Rear rail
33 3720-033 End cap
34 3720-034 Crank wheel knob
35 3720-035 Elevation wheel handle
36 3720-036 Washer
37 3720-037 Actuating arm
38 3720-038 Crank wheel clamping lever
39 3720-039 Bevel crank wheel
40 3720-040 Bevel locking lever
41 3720-041 Screw
42 3720-042 Screw
43 3720-043 Bevel clamp assembly
44 3720-044 Washer
45 3720-045 Angle locking bushing
46 3720-046 Compression spring
Item# Stock # Description
47 3720-047 Nut
48 3720-048 Washer
49 3720-049 Screw
50 3720-050 Pivot plate-Front
51 3720-051 Bushing
52 3720-052 Angle locking plate
53 3720-053 Screw
54 3720-054 Nut
55 3720-055 Screw
56 3720-056 Nylon nut
57 3720-057 Nylon nut
58 3720-058 Screw
59 3720-059 Spring washer
60 3720-060 Washer
61 3720-061 Bevel gear pad
62 3720-062 Bevel gear
63 3720-063 Screw
64 3720-064 Elevation crank shaft
65 3720-065 Pivot plate-Rear
66 3720-066 Rear mount
67 3720-067 Crank wheel cap
68 3720-068 Screw
69 3720-069 Crank wheel
70 3720-070 Bevel gear wheel
71 3720-071 Compression spring
72 3720-072 Front mount
73 3720-073 Angle adjustment wheel
74 3720-074 Square nut
75 3720-075 Bevel indicator
76 3720-076 Bushing - driving rod
77 3720-077 Bracket - driving rod
78 3720-078 Lock washer
79 3720-079 Bevel support indicator
80 3720-080 Motor bracket
81 3720-081 Fix bushing
82 3720-082 Screw
83 3720-083 Inner blade collar
84 3720-084 Blade
85 3720-085 Outer blade flange
86 3720-086 Arbor nut
87 3720-087 Dust chute
88 3720-088 Knob
89 3720-089 Wrench
90 3720-090 Knob ring
91 3720-091 Carriage bolt
