Wen 3720 User Manual

Item# Stock # Description
92 3720-092 Cord snapping ring
93 3720-093 Bolt
94 3720-094 Store holder
95 3720-095 Over-load protection
96 3720-096 Power cord
97 3720-097 Label
98 3720-098 Label
99 3720-099 Bevel scale
100 3720-100 Switch retainer
101 3720-101 Switch actuator assembly
102 3720-102 Switch bezel
103 3720-103 Switch box
104 3720-104 Pad
105 3720-105 Screw
106 3720-106 Push stick
107 3720-107 Power cord
108 3720-108 Outlet
109 3720-109 Cord clamp
110 3720-110 Cord storage
111 3720-111 Cabinet
112 3720-112 Warning label
113 3720-113 Nameplate
201 3720-201 Nut
202 3720-202 Gear housing
203 3720-203 Bearing
204 3720-204 C-ring
205 3720-205 Reduction gear
206 3720-206 C-ring
207 3720-207 Bearing
208 3720-208 Key
209 3720-209 Arbor
210 3720-210 Screw
211 3720-211 Bearing cover plate
212 3720-212 Washer
213 3720-213 Screw
214 3720-214 Bolt
215 3720-215 Motor end cap
216 3720-216 Brush holder
217 3720-217 spring
218 3720-218 Brush
219 3720-219 Motor housing
220 3720-220 Screw
221 3720-221 Spring washer
222 3720-222 Washer
223 3720-223 Motor housing field
Item# Stock # Description
224 3720-224 Bolt
225 3720-225 Baffle
226 3720-226 Bearing sleeve
227 3720-227 Armature assembly
228 3720-228 Fan
229 3720-229 Bearing
230 3720-230 Strain relief
231 3720-231 Motor connect line
301 3720-301 Miter gauge label
302 3720-302 Miter gauge
303 3720-303 Miter gauge indicator
304 3720-304 Steel ball
305 3720-305 Compression spring
306 3720-306 Bolt
307 3720-307 miter gauge rod
308 3720-308 Washer
309 3720-309 Bolt
310 3720-310 Wheel handle cap
311 3720-311 Miter gauge handle
312 3720-312 Washer
313 3720-313 Mier gauge scale
314 3720-314 Miter gauge pin
315 3720-315 Flat washer
316 3720-316 Screw
401 3720-401 Nylon nut
402 3720-402 Washer
403 3720-403 Clamp bushing
404 3720-404 Compression spring
405 3720-405 Riving knife deck
406 3720-406 Riving knife
407 3720-407 Riving knife clamp
408 3720-408 Riving lock lever
409 3720-409 Locking pin
410 3720-410 Screw
411 3720-411 Set screw
412 3720-412 Spring pin
501 3720-501 Warning label
502 3720-502 Guard nameplate
503 3720-503 Special spring
504 3720-504 Screw
505 3720-505 Bearing
506 3720-506 Blade guard-left
507 3720-507 Upper guard lever
508 3720-508 Top barrier
509 3720-509 label
EXPLODED VIEW & PARTS LIST
20

Wen 3720 Specifications

General

Brand	Wen
Model	3720
Category	Saw
Language	English
