Wen 3720 User Manual

Item# Stock # Description
510 3720-510 Coil spring
511 3720-511 Spring pin
512 3720-512 Pin
513 3720-513 Warning label
514 3720-514 Warning label
515 3720-515 Nut
516 3720-516 Blade guard-right
517 3720-517 Spring pin
518 3720-518 Guard nameplate
519 3720-519 Screw
520 3720-520 Washer
601 3720-601 Pin
602 3720-602 AKP-Left
603 3720-603 Button board
604 3720-604 Anti-kickback pawl
605 3720-605 Torsion spring
606 3720-606 AKP-Right
607 3720-607 Screw
608 3720-608 Washer
701 3720-701 Screw
702 3720-702 Washer
703 3720-703 Rip fence indicator
704 3720-704 Rip fence label
705 3720-705 Rip fence block
706 3720-706 Rip fence slider
707 3720-707 Micro adjust support
708 3720-708 Screw
709 3720-709 Screw
710 3720-710 Micro adjust wheel
711 3720-711 Fence handle
712 3720-712 Bushing - rip fence
713 3720-713 Rod - rip fence
714 3720-714 Label
715 3720-715 Screw
716 3720-716 Warning label
717 3720-717 Rip fence
718 3720-718 Compression Spring
719 3720-719 Rear fence slide
Item# Stock # Description
720 3720-720 Rear clamping plate
721 3720-721 Bolt
722 3720-722 Nut
723 3720-723 Rear channel cap
724 3720-724 Washer
801 3720-801 Support bar
802 3720-802 Screw
803 3720-803 Externsion block
804 3720-804 Fixed set
805 3720-805 Washer
806 3720-806 Screw
901 3720-901 Bolt
902 3720-902 Foot pad
903 3720-903 Rivet
904 3720-904 Upper stand
905 3720-905 Screw
906 3720-906 Small spacer
907 3720-907 Anti-loose nut
908 3720-908 Middle stand
909 3720-909 Round tube end cap
910 3720-910 Rear stand
911 3720-911 Wing nut
912 3720-912 support pad
913 3720-913 Big spacer
914 3720-914 Screw
915 3720-915 Stand locking plate
916 3720-916 Locking plate fix holder
917 3720-917 Fence spring
918 3720-918 Washer
919 3720-919 Anti-loose nut
921 3720-921 Flate washer
922 3720-922 Half hollow wheel
923 3720-923 Front stand
924 3720-924 Grip
925 3720-925 Grip
926 3720-926 grip overmold
927 3720-927 Upper stand end cap
EXPLODED VIEW & PARTS LIST
21
