Wen 56360iX User Manual

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
12 56360iX-112 Bolt, M5x8 1
13 56360iX-113 Clamp 1
14 56360iX-114 Fuel Hose 1
15 56360iX-115 Clamp 3
16 56360iX-116 Fuel Filter 1
17 56360iX-117 Switch Assembly 1
18 56360iX-118 Clamp 1
19 56202i-030 Damping Pad 2
20 56360iX-120 Fuel Tank 1
21 56202i-033 Nut 1
22 56360iX-122 Fuel Cap 1
23 56360iX-123 Left Hull Assembly 1
24 56202i-022 Alignment Bolt 6
25 56360iX-125 CO Alarm 1
26 56360iX-126 Left Cover Assembly 1
27 56360iX-127 Phillips Bolt 2
28 56360iX-128 Screw,ST4.2x13 2
29 56360iX-129
Service Window
Assembly
1
30 56202i-038
Self-tappling Screw,
ST4.2x9.5
1
31 56202i-039 Spark Arrestor 1
32 56360iX-132 O-Ring, Dipstick 1
33 56360iX-133 Engine 1
34 56360iX-134 Carbon Canister 1
35 56360iX-135 Fuel Hose 1
36 56360iX-136 Fuel Hose 2
37 56360iX-137 Roll Over Valve 1
38 56360iX-138 Fuel Hose 1
39 56360iX-139 Fuel Tee Pipe 1
40 56360iX-140 Fuel Hose 1
41 56360iX-141 Roll Over Valve 1
42 56360iX-142 Fuel Hose 1
43 56360iX-143 Fuel Tee Pipe 1
44 56360iX-144 Right Hull Assembly 1
45 56360iX-145
Right Cover
Assembly
1
46 56360iX-146 Shroud Cover 1
GENERATOR
33
NO. PART NO. DESCRIPTION QTY.
47 56360iX-147 Rectifier 1
48 56202i-053 Damping Pad 4
49 56202i-054 Damping Pad 1
50 56360iX-150 Switch Box Base 1
51 56360iX-151
Switch Box Base
Body
1
52 56202i-020
Fuel Tank Mount
Thread Tab
4
53 56202i-056 Nut, M6 4
54 56360iX-154 Rubber Cap 4
55 56202i-051 Bolt, M6x12 4
56 56360iX-156 Fuel Hose Jacket 1
57 56203i-005.14B
Parallel Outlet
(Black)
1
58 56203i-005.14R Parallel Outlet (Red) 1
59 56360iX-159 Nut, M6 1
60 56203i-005.11
Washer, φ6
1
61 56203i-005.12
Washer, φ6
1
62 56360iX-162 Earth Stud 1
63 56360iX-163
Washer, φ6
1
64 56360iX-164
Washer, φ5
1
65 56360iX-165
Washer, φ5
1
66 56360iX-166 Nut, M5 1
67 56360iX-167 Digital Meter 1
68 56203i-005.4 Eco-mode Switch 1
69 DG4500iX-207
NEMA TT-30R 120V
30A AC Outlet
1
70 DG4500iX-208
NEMA 5-20R 120V
20A AC Duplex
Outlet
1
71 56360iX-171 USB 1
72 56203i-005.2 DC 12V Outlet 1
73 56360iX-173 Breaker, AC 8A 1
74 56500-208 Breaker, AC 20A 1
75 56360iX-175 LED 1
76 56203i-005.5 Reset Button 1
