EXPLODED VIEW AND PARTS LIST
No. Part No. Description Qty.
1
56500-001
Handle Jacket 2
2 Push Handle 2
4 Handle Plug 2
3 56500-004 Cotter Pin (Handle) 2
5 56500-005 Handle Axle, φ10×40 2
6 56500-006 Frame Assembly 1
7 56500-007 Cotter Pin (Wheel) 2
8 56500-008 Washer, φ17.5xφ30x3 2
9 56500-008 Wheel 2
10 56500-009 Wheel Axle, φ16×85 2
11 56500-010 Damping Pad 3
12 56500-011 Clamp 1
13 56500-012 Fuel Switch 1
14 56500-013 Fuel Tank 1
15 56500-014 Pressure Relief Valve 1
16 56500-015 Fuel Gauge 1
17 56500-016 Washer, φ6.5×2×φ25 4
18 56500-017 Bolt, M6×25 4
19 56500-018 Fuel Cap 1
20 56500-019 Fuel Gauge Label 1
21 56500-020 Engine 1
22 56500-023 Muer Gasket 1
23
56500-024 Muer 1
56500-024.1 Spark Arrester 1
24 56500-025 Nut, M8 2
25 56500-026 Bolt, M8×16 2
26 56500-027 Bolt, M5×14 5
27 56500-028 End Cover 1
28 56500-029 Bolt, M5×18 3
29 56500-030 Voltage Regulator 1
30 56500-031 Carbon Brush Set 1
31 56500-032 Washer A, φ6 1
32 56500-033 Washer B, φ5 1
33 56500-034 Bolt, M6×150 4
34 56500-035 Rear Bracket 1
35 56500-036 Nut, M8 8
No. Part No. Description Qty.
36 56500-037 Reinforcement Support 1
37 56500-038
Damping Bracket (Right
Rear)
2
38 56500-1038 Washer B, φ6 1
39 56500-039
Damping Bracket (Left
Rear)
2
40 56500-040 Bolt, M10-1.25x225 1
41 56500-041 Washer A, φ10 1
42 56500-042 Washer B, φ10 1
43 56500-043 Alternator 1
44 56500-1044
Damping Bracket (Right
Front)
1
45 56500-1045
Damping Bracket (Left
Front)
1
46 56500-1046 Flange Bolt M8x16 2
47 56500-1047 Bolt M6x12 5
48 56500-044 Nut, M6 2
49 56500-045 Washer, M6 2
50 56500-046 Control Panel Assembly 1
51 56500-047 Clamp A 2
52 56500-052 Clamp A, Carbon Tank 3
53 56500-049 Carbon Tank 1
54 56500-050 Tube A, Carbon Tank 1
55 56500-051 Tube B, Carbon Tank 1
56 56500-053 Clamp B, Carbon Tank 2
57 56500-057 Support Base Assembly 1
58 56500-058 Support Base 1
59 56500-059
Damping Pad,
Support Base
2
60 56500-054 Bolt, M6x18 2
61 56500-060 Bolt, M8x16 2
62 56500-055 Bushing 2
63 56500-056 Flanged Lock Nut, M8 2
27
