Wen 56500 User Manual

EXPLODED VIEW AND PARTS LIST
No. Part No. Description Qty.
1 56500-017 Bolt, M6×25 7
2 56500-102 Valve Cover 1
3 56500-103 Breather Hose 1
4 56500-104 Gasket, Valve Cover 1
5 56500-105 Rivet, M3×8 2
6 56500-106 Breather Plate 1
7 56500-107 Breather Valve 1
8 56500-108 Inner Cover, Valve Cover 1
9 56500-109 Screw, M5×12 4
10 56500-110 Gasket, Valve Cover 1
11 56500-111 Rocker Arm Assembly 2
12 56500-112 Rocker Arm Base 1
13 56500-113 Valve Locker 4
14 56500-114 Valve Spring Seat 2
15 56500-115 Valve Spring 2
16 56500-116 Intake Valve Seal 1
N. P. 56500-116.1 Exhaust Valve Seal 1
17 56500-117 Nut, M8 4
18 56500-022 Bolt, M6×12 13
19 56500-119 Shroud 1
20 56500-1120 Shroud Mounting Clasp 1
21 56500-122 Cylinder Head 1
22 56500-123 Spark Plug F6TC (NGK BP6ES) 1
23 56500-124 Stud 1
24 56500-125 Stud, M6×90 2
25 56500-126 Gasket, Carburetor Insulator 1
26 56500-127 Insulator 1
27 56500-128 Gasket, Carburetor 1
28 56500-129 Carburetor 1
29 56500-130 Gasket Carburetor 1
30 56500-131 Air Filter Assembly 1
31 56500-132 Air Filter Base Assembly 1
32 56500-133 Air Filter Bae 1
33 56500-134 Air Filter Element 1
34 56500-135 Air Filter Cover 1
35 56500-136 Bolt 1
36 56500-137 Nut, M6 2
37 56500-138 Stud, M8×60 4
38 56500-139 Gasket, Cylinder Head 1
39 56500-140 Pin,φ10×14 2
40 56500-141 Intake Valve 2
41 56500-142 Exhaust Valve 1
42 56500-143 Piston Ring Set 1
43 56500-144 Push Rod 2
44 56500-145 Tappet 1
45 56500-146 Piston 1
46 56500-147 Circlip 2
47 56500-148 Piston Pin 1
48 56500-149 Connecting Rod Assembly 1
No. Part No. Description Qty.
49 56500-150 Oil Sensor 1
50 56500-151 Bolt, M6×18 2
51 56500-1151 Crankshaft Bearing 2
52 56500-152 Crankshaft Assembly 1
53 56500-153 Woodru Key 1
54 56500-155 Camshaft 1
55 56500-156 Pin,φ8×14 2
56 56500-157 Gasket, Crankcase 1
57 56500-158 Crankcase Cover 1
58 56500-159 Oil Seal, φ25×φ41.25×6 1
59 56500-160 Bolt, M8x35 1
60 56500-161 Dipstick Assembly 1
61 56500-163 Dipstick 1
62 56500-162 O-Ring, φ15.8×2.5 1
63 56500-164 Governor Gear 1
64 56500-165 Governor Gear Shaft 1
65 56500-166 O-Ring, φ5.2x1.9 1
66 56500-167 Oil Seal, φ6xφ11x4 1
67 56500-168 Cotter Pin 1
68 56500-169 Governor Lever 1
69 56500-170 Choke Linkage Lock Clamp 1
70 56500-171 Throttle Linkage 1
71 56500-172 Idle Spring 1
72 56500-173 Governor Spring 1
73 56500-174 Throttle Adjust Bracket Assembly 1
74 56500-175 Governor Gear Bracket Assembly 1
75 56500-176 Fuel Hose, φ4×φ10×126 1
76 56500-177 Clamp, Fuel Hose 1
77 56500-178 Clip 1
78 56500-179 Drainage Bolt 1
79 56500-180 Washer, φ10xφ16x1.5 1
80 56500-181 Crankcase 1
81 56500-182 Oil Seal, φ27×φ47×7 1
82 56500-183 Ignition Module 1
83 56500-184 Wire Board 1
84 56500-185 Flywheel 1
85 56500-186 Cooling Fan 1
86 56500-187 Starter Cup 1
87 56500-188 Nut, M14×1.5 1
88 56500-189 Recoil Starter Assembly 1
89 56500-190 Blower Housing 1
90 56500-191 Recoil Starter 1
91 56500-192 Washer, φ6 3
92 56500-193 Bolt, M6×10 3
93 56500-1193 Air Filter Bracket 1
94 56500-1194 Clip 1
95
56500-
1195ASM
Valve Cover Assembly 1
29
