Wen 70712

17
EXPLODED VIEW & PARTS LIST
Item Stock # Description Qty
1 70712B-001 Bolt M8X30 1
2 70712B-002 Nut 2
3 70712B-003 Slide lock knob 1
4 70712B-004 Spring 1
5 70712B-005 Washer 1
6 70712B-006 Arm 1
7 70712B-007 Flange 2
8 70712B-008 Pole 2
9 70712B-009 back stand 1
10 70712B-010 Bolt 1
11 70712B-011 Line button 2
12 70712B-012 Bolt 4
13 70712B-013 Bolt 4
14 70712B-014 Washer 2
15 70712B-015 Bevel lock knob 1
16 70712B-016 Nut 2
17 70712B-017 Washer 2
18 70712B-018 Washer 1
19 70712B-019 Pointer 1
20 70712B-020 Washer 5
21 70712B-021 Washer 4
22 70712B-022 Bolt 1
23 70712B-023 Pole 1
24 70712B-024 Knob 1
25 70712B-025 Wing bolt 2
26 70712B-026 Clamp 1
27 70712B-027 Clamp slice 1
28 70712B-028 Block circle 1
29 70712B-029 Bolt 2
30 70712B-030 Washer 8
31 70712B-031 Wing bolt 2
32 70712B-032 Right slid Fence 1
33 70712B-033 Fence 1
34 70712B-034 left slid fence 1
35 70712B-035 Support arm 2
36 70712B-036 Base 1
37 70712B-037 Bolt 1
38 70712B-038 Knob 3
39 70712B-039 Rubber foot 4
40 70712B-040 locking bar 1
41 70712B-041 Washer 1
42 70712B-042 Spring 2
43 70712B-043 Miter release handle 1
44 70712B-044 Miter lock knob 1
45 70712B-045 Bolt 1
46 70712B-046 Table 1
47 70712B-047 Nut 1
48 70712B-048 bolt 7
49 70712B-049 Spring card 1
50 70712B-050 Pointer 1
51 70712B-051 scale label 1
52 70712B-052 bolt 1
Item Stock # Description Qty
53 70712B-053 bolt 1
54 70712B-054 Change block 1
55 70712B-055 Washer 1
56 70712B-056 Nut 1
57 70712B-057 Table insert 1
58 70712B-058 Release knob 1
59 70712B-059 Spring 1
60 70712B-060 Pin 1
61 70712B-061 Pin 1
62 70712B-062 Bearing 3
63 70712B-063 Stand 1
64 70712B-064 Bolt 1
65 70712B-065 Spring 1
66 70712B-066 Pin 1
67 70712B-067 Plastic cover 1
68 70712B-068 Guard retraction arm 1
69 70712B-069 Bolt 2
70 70712B-070 Needle bearing 1
71 70712B-071 Block circle 1
72 70712B-072 Gear 1
73 70712B-073 Front cover 1
74 70712B-074 bearing 1
75 70712B-075 Bearing cover 1
76 70712B-076 Washer 2
77 70712B-077 Bolt 2
78 70712B-078 Output shaft 1
79 70712B-079 Half round key 1
80 70712B-080 Inner flange 1
81 70712B-081 Blade 1
82 70712B-082 Outer flange 1
83 70712B-083 Arbor bolt 1
84 70712B-084 Blade cover 1
85 70712B-085 Dust collection bag 1
86 70712B-086 Gear cover 1
87 70712B-087 Spindle lock button 1
88 70712B-088 Spring 1
89 70712B-089 Block circle 1
90 70712B-090 Bearing 1
91 70712B-091 Rotor 1
92 70712B-092 Bearing 1
93 70712B-093 Block circle 1
94 70712B-094 Bolt 2
95 70712B-095 Stator 1
96 70712B-096 Motor house 1
97 70712B-097 Brush hold cover 2
98 70712B-098 Carbon brush 2
99 70712B-099 Brush hold 2
100 70712B-100 Washer 4
101 70712B-101 Washer 4
102 70712B-102 Bolt 4
103 70712B-103 Bolt 2
104 70712B-104 Carry handle 1
