Wen 71745 User Manual

EXPLODED VIEW AND PARTS LIST
No. Part No. Description Qty.
1 71745-001 Carrying Handle 1
2 71745-002 Base 1
3 71745-003
Cross Head Self-Tapping
Screw ST4.2X16
8
4 71745-004 Rubber Foot 4
5 71745-005 Power Switch 1
6 71745-006 Terminal 4
7 71745-007 Terminal Tube 6
8 71745-008
Cross Head Self-Tapping
Screw ST4.2X13
5
9 71745-009 Wire Storage 1
10 71745-010 Power Cord Sleeve 1
11 71745-011 Power Cord Three-Prong 1
12 71745-012 Flat Washer D4 8
13 71745-013 Motor Plate 1
14 71745-014 Rubber Insert A 1
16 71745-016 Motor 1
17 71745-017 Star Washer D4 1
18 71745-018 Grounding Pin 1
19 71745-019 Spring Washer D4 5
20 71745-020 Cross Head Screw M4X8 1
21 71745-021 Ground Label 1
22 71745-022 Motor Bracket 1
23 71745-023 Cross Head Screw M4X12 3
24 71745-024 O Ring Ø22.4X2.65 1
25 71745-025 Table Top 1
26 71745-026 Label 1
27 71745-027 Fence Lock Knob 2
28 71745-028 Parallel Fence 1
29 71745-029 Miter Gauge A 1
30 71745-030 Miter Gauge B 1
31 71745-031 Flat Washer D6 2
No. Part No. Description Qty.
32 71745-032 Miter Gauge Knob 1
33 71745-033 Upper Guard Knob 1
34 71745-034 Upper Guard Bolt 1
35 71745-035 Upper Blade Guard 1
36 71745-036 Cross Hand Screw M4X20 1
37 71745-037 Metal Bracket 1
38 71745-038
Cross Head Sunk Screw
ST2.9X16
3
39 71745-039 Table Insert 1
40 71745-040
45° Bevel Table
1
41 71745-041 Stop Plate 1
42 71745-042 Inner Flange 1
43 71745B
Diamond Blade (mm)
Ø115×Ø15.88×1.2×2.1
1
44 71745-044 Outer Flange 1
45 71745-045 Nut M8 1
46 71745-046 Lower Blade Guard 1
47 71745-047 Chain 1
48 71745-048 Tank Drain Plug 1
49 71745-049 O Ring Ø 23.6×2.65 1
50 71745-050 Scale Label 1
51 71745-051 Main Label 1
54 71745-054 Rubber Insert B 1
55 71745-055 Insert Pad 1
56 71745-056 Flat Wire 2X18AWG 1
58 71745-058 Wrench A 1
59 71745-059 Wrench B 1
60 71745-060 Switch Plate 1
61 71745-061 Terminal 2
62 71745-062 Brush Holder 2
63 71745-063 Carbon Brush 2
19
