Wen CM1452

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 CM1452-001 Screw M5x12 2
2 CM1452-002 Motor Cap 1
3 CM1452-003 Bearing Support Plate 1
4 CM1452-004 Wave Washer 1
5 CM1452-005 Screw M5x10 2
6 CM1452-006 Red Gasket 2
7 CM1452-007 Motor Label 1
8 CM1452-008 Bolt M5x15 2
9 CM1452-009 Depth Stop 1
10 CM1452-010 Motor Housing 1
11 CM1452-011 Warning Label 1
12 CM1452-012 Washer 5 mm 1
13 CM1452-013 Screw M5x10 1
14 CM1452-014 Left Handle 1
15 CM1452-015 Screw ST4.2x25 1
16 CM1452-016 Screw M5x60 2
17 CM1452-017 Screw M5x30 1
18 CM1452-018 Screw ST4.2x13 2
19 CM1452-019 Cable Clamp 1
20 CM1452-020 Cable Sheath 1
21 CM1452-021 Power Cord 1
22 CM1452-022 Right Handle 1
23 CM1452-023 Switch Knob 1
24 CM1452-024 Nut M5 6
25 CM1452-025 Screw ST4.2x16 9
26 CM1452-026 Lower Handle 1
27 CM1452-027 Safety Button 1
28 CM1452-028 Switch Button Spring 1
29 CM1452-029 Upper Handle 1
30 CM1452-030 Screw ST4.2x13 2
31 CM1452-031 Switch 1
32 CM1452-032 Capacitor 1
33 CM1452-033 Protective Ring 1
34 CM1452-034 Brush Holder 2
35 CM1452-035 Carbon Brush 2
36 CM1452-036 Brush Cap 2
37 CM1452-037 Stator 1
38 CM1452-038 Spring Washer 5 2
No. Part No. Description Qty.
39 CM1452-039 Screw M5x80 2
40 CM1452-040 Air Baffle 1
41 CM1452-041 Bearing 6200 1
42 CM1452-042 Rotor 1
43 CM1452-043 Bearing 6202 1
44 CM1452-044 Inner Gearbox 1
45 CM1452-045 Locating Pin 2
46 CM1452-046 Stop Pin Spring 1
47 CM1452-047 Split Washer 8 1
48 CM1452-048 Arbor Lock 1
49 CM1452-049 Bearing 6000 1
50 CM1452-050 Gear 1
51 CM1452-051 Flat Key 5x12 1
52 CM1452-052 Small Output Shaft 1
53 CM1452-053 Bearing 6200 1
54 CM1452-054 Bearing 6001 1
55 CM1452-055 Gear Big 1
56 CM1452-056 Flat Key 6x12 1
57 CM1452-057 Large Output Shaft 1
58 CM1452-058 Bearing 6204 1
59 CM1452-059 Outer Gearbox 1
60 CM1452-060 Gearshaft Cover 1
61 CM1452-061 Screw M4x12 3
62 CM1452-062 Safety Guard Label 1
63 CM1452-063 Plastic Safety Guard 1
64 CM1452-064 Bolt M4x10 2
65 CM1452-065 Inner Guard Plate 1
66 CM1452-066 Screw M5x90 4
67 CM1452-067 Screw M5x12 1
68 CM1452-068 Rubber Ring 2
69 CM1452-069 Flat Washer 4 2
70 CM1452-070 Spring Washer 4 2
71 CM1452-071 Screw M4x10 2
72 CM1452-072 Tension Spring 2 1
73 CM1452-073 Screw M4x10 2
74 CM1452-074 Left Movable Cover 1
75 CM1452-075 Right Movable Cover 1
76 CM1452-076 Connection Rod 1 1
NOTE: Not all parts may be available for purchase.
