Wen CM1452 User Manual

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
77 CM1452-077 Screw 4 4
78 CM1452-078 Connection Rod 2 1
79 CM1452-079 Tension Spring 1
80 CM1452-080 Circlip For Shaft 1
81 CM1452-081 Inner Flange 1
82 CM1452-082 Outer Safety Guard 1
83 CM1452-083 Spring Washer 4 4
84 CM1452-084 Screw M4x10 4
85 CM1452-085 Blade Guard Label 1
86 CM1452-086 Arbor Cover Plate 1
87 CM1452-087 Positioning Washer 1
88 CM1452-088 Set Screw 1
89 CM1452-089 Blade Cover Label 1
90 CM1452-090 Blade Cover Screw 1
91 BL1466 Blade 1
92 CM1452-092 Outer Flange 1
93 CM1452-093 Blade Washer 1
94 CM1452-094 Spring Washer 10 1
95 CM1452-095 Bolt M10x30 1
96 CM1452-096 Crank Handle Knob 1
97 CM1452-097 Vise Screw 1
98 CM1452-098
Quick Release
Mechanism
1
99 CM1452-099 Pin 6x35 1
100 CM1452-100 Vise Screw Support 1
101 CM1452-101 Vise Screw Washer 1
102 CM1452-102 Flat Washer 8 2
103 CM1452-103 Locking Nut 10 1
104 CM1452-104 Washer 1
105 CM1452-105 Jaw Connection Rod 1
106 CM1452-106 Cotter Pin 3x26 1
107 CM1452-107 Vise Jaw 1
108 CM1452-108 Circlip For Shaft 22 1
109 CM1452-109 V-Vise Cover 1
110 CM1452-110 Vise Fence 1
111 CM1452-111 Screw Washer 1
112 CM1452-112 Flat Washer 10 2
113 CM1452-113 Spring Washer 10 2
114 CM1452-114 Bolt M10x20 1
No. Part No. Description Qty.
115 CM1452-115 Screw 1
116 CM1452-116 Fence Miter Handle 1
117 CM1452-117 Handle Spring 1
118 CM1452-118 Coupling Screw 1
119 CM1452-119 Miter Scale 1
120 CM1452-120 Rivet 3x18 2
121 CM1452-121 Kerf Panel 1
122 CM1452-122 Bolt M8x40 2
123 CM1452-123 Spring Washer 8 2
124 CM1452-124 Flat Washer 8 2
125 CM1452-125 Bolt M8x35 2
126 CM1452-126 Rubber Foot 2
127 CM1452-127 Dust Drawer 1
128 CM1452-128 Dust Drawer Base 1
129 CM1452-129 Screw M4x10 10
130 CM1452-130 Saw Base 1
131 CM1452-131 Wrench Holder 1
132 CM1452-132 Screw M5x15 2
133 CM1452-133 Wrench Ring 1
134 CM1452-134 Hex Wrench 8mm 1
135 CM1452-135 Bolt M8x40 1
136 CM1452-136 Spring Washer 8 1
137 CM1452-137 Flat Washer 8 1
138 CM1452-138 Plunge Lock 1
139 CM1452-139 Pin 3x18 1
140 CM1452-140 Plunge Lock Rod 1
141 CM1452-141 Plunge Lock Spring 1
142 CM1452-142 Plunge Lock Pin 1
143 CM1452-143 Circlip 24 2
144 CM1452-144 Axle 1
145 CM1452-145 Torsion Spring 1
146 CM1452-146 Nut M6 1
147 CM1452-147
Depth Stop Screw
M8x50
1
148 CM1452-148 Bolt M5x8 2
149 CM1452-149 Flat Washer 6 2
150 CM1452-150 Spring Washer 6 2
151 CM1452-151 Bolt M6x20 2
152 CM1452-152 Connection Plate 1
22
