Wen DF1100

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 DF1100-001 Rotor & Stator Assembly 1
1.1 DF475-001.1 Carbon Brush Assembly 1
1.2 DF475-001.2 Grounding Post Assembly 1
1.3 DF1100-001.3 Rotor 1
1.4 DF1100-001.4 Stator 1
2 DF1100-002 Motor Stand 1
3 DF1100-003 Bolt M5X230 2
4 DF1100-004 Nut M5 2
5 DF1100-005 Flat Washer Ø5 2
6 DF1100-006 Spring Washer Ø5 3
7 DF1100-007 Frame 1
8 DF1100-008 Rack Cable 1
9 DF1100-009 Isolator B 4
10 DF475-010 Fuel Filter 1
11 DF1100-011 Fuel Tank Assembly 1
12 DF475-012 Fuel Cock 1
13 DF1100-013 Regulator Assembly 1
14 DF475-014 LPG Hose Assembly 1
15 DF1100-015 Crankcase Guard Cover 1
16 DF1100-016 Flat Washer 2
17 DF1100-017 Bolt M10X1.25X283 1
18 DF475-016 Gasket, Rotor Bolt Ø10.5XØ30X4 1
19 DF1100-019 Handle Assembly 2
20 DF1100-020 Bolt M6X195 4
21 DF1100-021 Bolt M6X12 9
22 DF1100-022 Nut M10 4
23 DF1100-023 Air Cleaner Bracket 1
24 DF1100-024 Exhaust Pipe Gasket 1
25 DF1100-025 Cotter Pin 2
26 DF1100-026 Muffler Assembly 1
27 DF1100-027 Spring Washer 2
28 DF1100-028 Bolt M8X30 2
29 DF1100-029 Panel Assembly 1
29.1 DF475-029.1 Ignition Switch 1
N/A P55340 Starter Key (Set of 2) 2
29.2 DF475-029.4 NEMA 5-20R 120V 20A GFCI Duplex 2
29.3 DF1100-029.3 AC Thermal Protector 20A/CSA 2
29.4 DF1100-029.4 Multifunction Meter 1
29.5 DF475-029.2 DC Receptacle 12V 1
29.6 DF1100-029.6 Thermal Protector 35A/CSA 2
29.7 DF1100-029.7 NEMA L14-30R 120V/240V 30A 1
29.8 DF1100-029.8 NEMA L14-50R 120V/240V 50A 1
29.9 DF1100-029.9 DC Thermal Protector 8A/CSA 1
29.10 DF1100-029.10 AC Thermal Protector 35A/CSA 2
29.11 DF1100-029.11 Rectifier/Charger 1
30 DF1100-030 Handle Plug 2
31 DF1100-031 Bolt M8X45 2
32 DF1100-032 Bolt M6X25 2
33 DF1100-033 Automatic Voltage Regulator (AVR) 1
No. Part No. Description Qty.
34 DF475-034 Bolt M5X16 3
35 DF475-035 Bolt M5X12 5
36 DF475-036 Fuel Tank Washer 4
37 DF475-037 Bolt M6X25 4
38 DF1100-038 Generator End Cover 1
39 DF475-039 Positive Lead 1
40 DF1100-040 Negative Lead 1
41 DF1100-041 Battery 1
42 DF1100-042 Wheel 2
43 DF1100-043 Foot Support Assembly 2
44 DF1100-044 Vibration Isolation Pad 2
45 DF475-045 Nut M6 3
46 DF475-046 Bolt M8X16 4
47 DF475-047 Clip Ø12 2
48 DF1100-048 Wheel Axel 2
49 DF475-005 Bolt M8X16 4
50 DF1100-050 Muffler Bracket 1
51 DF1100-051 Tie Wrap 1
52 DF475-063 Fuel Line Clip Ø10 1
53 DF1100-053 Low Pressure Pipe 1
54 DF1100-054 Toothed Washer Ø5 1
55 DF1100-055 Fuel Line (Fuel Cock) 1
56 DF475-055 Fuel Line 1
57 DF1100-057 Connecting Pipe (Gas Tank) 1
58 DF1100-058 Manual Choke Assembly 1
59 DF475-003 Fuel Selector Switch (Panel) 1
60 DF475-060 Clip, Fuel Line Ø7.5 1
61 DF475-061 Clip, Fuel Line Ø9.5 5
62 DF1100-062 Dustproof Sheet (Right) 1
63 DF475-004 Hex Pan Head Screw M6X12 1
64 DF475-064 Nut M6 4
65 DF475-073 Fuel Tank Cap Assembly 1
66 DF475-022 Nut M5 3
67 DF1100-067 Handle Bush 4
68 DF1100-068 Dustproof Sheet (Left) 1
69 DF1100-069 One-Way Valve Gasket Washer 1
70 DF475-070 Fuel Selector Switch 1
71 DF1100-071 Crossing Screw M5X12 3
72 DF475-072 Paper Washer 4
73 DF1100-073 Handle Rubber 2
74 DF1100-074 Grounding Wire 1
75 DF1100-075 Carbon Tank Assembly 1
76 DF475-074 LPG Regulator Cover 1
77 DF1100-077 Lock Nut M8 2
79 DF1100-079 Connecting Pipe 1
80 DF1100-080 Fuel Gauge 1
81 DF1100-081 Fuel Tank Filter 1
82 DF1100-082 Engine Complete 1
