Wen DF1100

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 DF1100-101 Crankcase 1
2 DF1100-102 Ball Bearing (Small) 2
3 DF1100-103 Oil Seal 2
4 DF1100-104 Governor Arm Shaft Seal 1
5 DF1100-105 Governor Arm Shaft 1
6 DF1100-106 Governor Arm Shaft Washer 1
7 DF1100-107 Lock Pin 1
8 DF1100-108 Drain Plug Bolt 2
9 DF1100-109 Drain Plug Washer 2
10 DF1100-110 Oil Level Switch Assembly 1
11 DF1100-111 Bolt M6X16 2
12 DF1100-112 Casecover Dowel Pin 2
13 DF1100-113 Piston 1
14 DF1100-114 Piston Scraper Ring Set 1
15 DF1100-115 Connecting Rod Assembly 1
16 DF1100-116 Piston Pin 1
17 DF1100-117 Piston Clip 2
18 DF1100-118 Crank Casecover Assembly 1
19 DF1100-119 Ball Bearing (Big) 1
20 DF1100-120 Governor Assembly 1
21 DF1100-121 Cylinder Head 1
22 DF1100-122 In Valve 1
23 DF1100-123 Valve Exhaust 1
24 DF1100-124 Intake Valve Returner 2
25 DF1100-125 Valve Oil Seal 2
26 DF1100-126 Valve Spring 2
27 DF475-132 Fuel Line (Carburetor) 1
28 DF1100-128 Ex Valve Spring Seat 2
29 DF1100-129 Push Rod Guide Plate 1
30 DF1100-130 Rocker Assembly 2
31 DF1100-131 Rotator 2
32 DF1100-132 Stud Bolt (Carburetor) 2
33 DF1100-133 Stud Bolt (Exhaust) 2
34 DF1100-134 Exhaust Gasket 1
35 DF1100-135 Dipstick 1
36 DF1100-136 Spring Washer 2
37 DF1100-137 Nut M8 2
38 DF1100-138 Carburetor Assembly 1
39 DF1100-139 Governor Arm 1
40 DF1100-140 Governor Arm Bolt 1
41 DF1100-141 Nut M6 3
42 DF1100-142 Crankshaft Assembly 1
No. Part No. Description Qty.
43 DF1100-143 Valve Lifter 2
44 DF1100-144 Casecover Gasket 1
45 DF1100-145 Balancing Shaft 1
46 DF1100-146 Camshaft Assembly 1
47 DF1100-147 Bolt M8X35 2
48 DF1100-148 Bolt M8X40 7
49 DF1100-149 Dowel Pin 2
50 DF1100-150 Cylinder Head Gasket 1
51 DF1100-151 Bolt M10X80 4
52 DF475-145 Spark Plug 1
53 DF1100-153 Push Rod 2
54 DF1100-154 Shroud 1
55 DF1100-155 Bolt M6X12 9
56 DF1100-156 Cylinder Head Cover Assembly 1
57 DF1100-157 Head Cover Gasket 1
58 DF1100-158 Lock Bolt 1
59 DF1100-159 Upper Shroud Assembly 1
60 DF1100-160 Flywheel Assembly 1
61 DF1100-161 Recoil Starter Fan 1
62 DF1100-162 Starter Pulley 1
63 DF1100-163 Nut Flywheel 1
64 DF1100-164 Rubber Starter Assembly 1
65 DF1100-165 Ignition Coil Assembly 1
66 DF1100-166 Bolt M6X25 2
67 DF1100-167 Intake Gasket 1
68 DF1100-168 Carburetor Insulator 1
69 DF1100-169 Carburetor Gasket 1
70 DF1100-170 Adjuster Rocker Arm 2
71 DF1100-171 Exhaust Pipe 1
72 DF1100-172 Governor Rod 1
73 DF1100-173 Throttle Return Spring 1
74 DF1100-174 Recoil Starter Assembly 1
74.1 DF1100-174.1 Recoil Starter 1
75 DF1100-175 Air Cleaner Assembly 1
75.1 DF1100-175.1 Air Filter Element 1
76 DF1100-176 Breather Tube 1
77 DF1100-177 Governor Spring 1
78 DF1100-178 Locking Flaps 4
79 DF1100-179 Clip 2
80 DF1100-180 Fuel Rubber 1
81 DF1100-181 Air Cleaner Gasket 1
82 DF1100-182 Fuel Line Clip 1
83 DF1100-183 Starting Motor Assembly 1
37
