TABLE OF CONTENTS
Introduction ............................................................................................. 2
Safety Information ................................................................................... 4
Generator Safety Warnings ......................................................................5
Know Your Generator ............................................................................... 8
Unpacking & Assembly .......................................................................... 10
Generator Preparation ............................................................................ 12
Starting the Generator ............................................................................ 19
Using the Generator ............................................................................... 21
Shutting Off the Generator ..................................................................... 24
Maintenance ........................................................................................... 25
Transportation & Storage ....................................................................... 32
Specifications ......................................................................................... 33
Exploded View & Parts List .................................................................... 34
Wiring Diagram ...................................................................................... 38
Troubleshooting Guide ........................................................................... 39
Warranty Statement ...............................................................................40
KEY SPECIFICATIONS
Model Number DF475, DF475T
Rated Wattage Gasoline: 3800 Watts, LPG: 3500 Watts
Surge Wattage Gasoline: 4750 Watts, LPG: 4350 Watts
Frequency 60Hz
Rated Voltage AC: 120V/240V, DC: 12V
Rated Amperage AC: 32A/16A, DC: 8A
Engine OHV, 4 stroke, single cylinder, 224cc
Fuel Tank Capacity 4 US gallons (15 L), 87 octane minimum
Oil Capacity 20.3 fl. oz. (0.6 L)
Half-Load Run Time
Gasoline: 11 hours
LPG (with 20 lb tank): 7 hours
Product Dimensions 23.2 x 17.5 x 18.5 in. (L x W x H)
Product Net Weight 105.8 lbs (48 kg)
2
Your generator is compatible with the WEN 55201 Magnetic Oil Dipstick,
available at wenproducts.com
