SPECIFICATIONS
Rated Wattage
Gasoline: 3800 Watts
LPG: 3500 Watts
Surge Wattage
Gasoline: 4750 Watts
LPG: 4350 Watts
Phase Single
Frequency 60Hz
Rated Voltage AC: 120V/240V, DC: 12V
Rated Amperage AC: 32A/16A, DC: 8A
Product Dimensions 23.2 x 17.5 x 18.5 in. (L x W x H)
Product Net Weight 105.8 lbs (48 kg)
Engine Type 4-stroke, OHV, single cylinder with forced air cooling system
Engine Displacement 224cc
Engine Horsepower 6 HP at 3600 RPM
Fuel Type Gasoline and LPG
Gas Tank Capacity 4 US Gallons (15 L), 87 octane minimum
Oil Capacity 20.3 fl. oz. (0.6 L)
Half-Load Run Time
Gasoline: 11 hours
LPG (with 20 lb tank): 7 hours
Spark Plug Type Torch F7TC/NGK BP7ES
Spark Plug Gap 0.7 - 0.8 mm (0.028 - 0.031 in)
Spark Plug Torque 1/2 - 3/4 turn after gasket contacts base or 15 ft-lbs
Length of LPG Cable 47 inches (1200 mm)
GENERATOR
ENGINE
33
IMPORTANT: Repairs and replacements should only be performed by an authorized technician. Parts and ac-
cessories that wear down over the course of normal use are NOT covered by the two-year warranty.
