EXPLODED VIEW & PARTS LIST
35
No. Part No. Description Qty.
1 DF475-001 Rotor Stator Assembly 1
1.1 DF475-001.1 Carbon Brush Assembly 1
1.2 DF475-001.2 Grounding Post Assembly 1
1.3 DF475-001.3 Rotor 1
1.4 DF475-001.4 Stator 1
2 DF475-002 Motor Stand 1
3 DF475-003 Switch Dial Assembly 1
4 DF475-004
Hexagon Pattern Pan Head Screws
M6X12
1
5 DF475-005 Nut M8 6
6 DF475-006 Wire Harness Clip 1
7 DF475-007 Frame 1
8 DF475-008 Isolator A 2
9 DF475-009 Isolator B 2
10 DF475-010 Fuel Filter 1
11 DF475-011 Fuel Tank Assembly 1
12 DF475-012 Fuel Cock 1
13 DF475-013 Regulator Assembly 1
14 DF475-014
LPG Hose Assembly
1
15 DF475-015 Bolt M6X55 1
16 DF475-016 Flat Washer 2
17 DF475-017 Bolt M8X1X220 1
18 DF475-018 Rotor Bolt Gasket Ø8.5X24X3 1
19 DF475-019 Handle Assembly 1
20 DF475-020 Bolt M6X175 4
21 DF475-021 Bolt M6X12 5
22 DF475-022 Nut M5 3
23 DF475-023 Air Cleaner Bracket 1
24 DF475-024 Exhaust Gasket 1
25 DF475-025 Cotter Pin 2
26 DF475-026 Muffler Assembly 1
27 DF475-027 Spring Washer Ø8 2
28 DF475-028 Bolt M6X40 2
29 DF475-029 Control Panel Assembly 1
29.1 DF475-029.1 Ignition Switch 1
29.2 DF475-029.2 DC Receptacle 12V 1
29.3 DF475-029.3 Thermal Protector 8A/CSA 1
29.4 DF475-029.4
NEMA 5-20R 120V 20A GFCI
Duplex
1
29.5 DF475-029.5 Thermal Protector 20A/CSA 1
29.6 DF475-029.6 120V/240V Voltage Selector 1
29.7 DF475-029.7 Thermal Protector 16A/CSA 2
29.8 DF475-029.8
NEMA L14-30R 125V/250V 30A
Twistlock
1
29.9 DF475-029.9 Grounding Nut 1
29.10 DF475-029.10 Rectifier/Charger 1
N/A P55340 Starter Key (Set of 2) 2
30 DF475-030 Handle Clip 1
31 DF475-031 Bolt M8X35 2
32 DF475-032 Bolt M6X40 4
No. Part No. Description Qty.
33 DF475-033 Automatic Voltage Regulator 1
34 DF475-034 Bolt M5X16 1
35 DF475-035 Bolt M5X12 7
36 DF475-036 Fuel Tank Washer 4
37 DF475-037 Bolt M6X25 4
38 DF475-038 Generator End Cover 1
39 DF475-039 Positive Lead 1
40 DF475-040 Negative Lead 1
41 DF475-041 Battery 1
42 DF475-042 Wheel 2
43 DF475-043 Frame Support 2
44 DF475-044 Vibration Isolation Pad 2
45 DF475-045 Nut M6 6
46 DF475-046 Bolt M8X16 2
47 DF475-047 Clip Ø12 3
48 DF475-048 Wheel Axle 2
49 DF475-049 Handle Connector 1
50 DF475-050 Muffler Bracket 1
51 DF475-051 Battery Holder 1
52 DF475-052 Isolator 2
53 DF475-053 Low Pressure Pipe 500mm 1
54 DF475-054 Low Pressure Pipe 250mm 1
55 DF475-055 Fuel Line (Ø8.5X4.5)/Ø10X6)X250 1
56 DF475-056 Fuel Line Ø10X6X120 1
57 DF475-057 Connecting Pipe (Gas Tank) 1
58 DF475-058 Manual Choke Assembly 1
59 DF475-059 Handle Bolt 1
60 DF475-060 Fuel Line Clip Ø7.5 1
61 DF475-061 Fuel Line Clip, Ø9.5 5
62 DF475-062 Frame Wire 1
63 DF475-063 Fuel Line Clip Ø10 2
64 DF475-064 Nut M8 7
65 DF475-065 Tooth Type Gasket Ø6 1
66 DF475-066 Tooth Type Gasket Ø5 1
67 DF475-067 Handle Rubber 1
68 DF475-068 Bolt M6X30 1
69 DF475-069 Grounding Wire 1
70 DF475-070 Fuel Selector Switch 1
71 DF475-071 Bolt M6X16 4
72 DF475-072 Paper Washer 4
73 DF475-073 Fuel Tank Cap Assembly 1
74 DF475-074 LPG Regulator Cover 1
75 DF475-075 Carbon Tank Assembly 1
76 DF475-076 Connecting Pipe 1
77 DF475-077 Dustproof Sheet 1
78 DF475-078 Fuel Gauge 1
79 DF475-079 Fuel Tank Filter 1
80 DF475-080 Engine Complete 1
