EXPLODED VIEW & PARTS LIST
37
No. Part No. Description Qty.
1 DF475-101 Crankcase 1
2 DF475-102 Ball Bearing 2
3 DF475-103 Oil Seal 2
4 DF475-104 Governor Assembly 1
5 DF475-105 Governor Arm Shaft 1
6 DF475-106 Governor Arm Shaft Washer 1
7 DF475-107 Lock Pin 1
8 DF475-108 Drain Plug Bolt 2
9 DF475-109 Drain Plug Washer 2
10 DF475-110 Oil Level Switch Assembly 1
11 DF475-111 Bolt M6X16 2
12 DF475-112 Casecover Dowel Pin Ø8X14 2
13 DF475-113 Piston 1
14 DF475-114 Piston Scraper Ring Set 1
15 DF475-115 Connecting Rod Assembly 1
16 DF475-116 Piston Pin 1
17 DF475-117 Piston Clip 2
18 DF475-118 CrankCasecover Assembly 1
19 DF475-119 Cylinder Head 1
20 DF475-120 In-Valve 1
21 DF475-121 Valve Exhaust 1
22 DF475-122 Intake Valve Returner 1
23 DF475-123 Valve Spring 2
24 DF475-124 In-Valve Spring Seat 1
25 DF475-125 Ex-Valve Spring Seat 1
26 DF475-126 Push Rod Guide Plate 1
27 DF475-127 Rocker Assembly 2
28 DF475-128 Rotator 1
29 DF475-129 Stud Bolt (Carburetor) 2
30 DF475-130 Stud Bolt 2
31 DF475-131 Carburetor Assembly 1
32 DF475-132 Fuel Line 1
33 DF475-133 Fuel Line Clip Ø7.5 1
34 DF475-134 Governor Arm 1
35 DF475-135 Governor Arm Bolt 1
36 DF475-136 Nut M6 3
37 DF475-137 Crankshaft Assembly 1
38 DF475-138 Valve Lifter 2
39 DF475-139 Casecover Gasket 1
40 DF475-140 Camshaft Assembly 1
No. Part No. Description Qty.
41 DF475-141 Dowel pin 2
42 DF475-142 Bolt M8X30 6
43 DF475-143 Cylinder Head Gasket 1
44 DF475-144 Bolt M8X60 4
45 DF475-145 Spark Plug 1
46 DF475-146 Push Rod 2
47 DF475-147 Shroud 1
48 DF475-148 Bolt M6x12 12
49 DF475-149 Headcover Gasket 1
50 DF475-150 Cylinder Head Cover 1
51 DF475-151 Wind Shield Assembly 1
52 DF475-152 Bolt M6x28 1
53 DF475-153 Recoil Starter Fan 1
54 DF475-154 Starter Pulley 1
55 DF475-155 Nut M14 1
56 DF475-156 Ignition Coil Assembly 1
57 DF475-157 Bolt M6X25 2
58 DF475-158 Intake Gasket 1
59 DF475-159 Carburetor Insulator 1
60 DF475-160 Carburetor Gasket 1
61 DF475-161 Carburetor Spacer 1
62 DF475-162 Governor Rod 1
63 DF475-163 Throttle Return Spring 1
64 DF475-164 Recoil Starter Assembly 1
64.1 DF475-164.1 Recoil Starter 1
65 DF475-165 Upper Shroud Assembly 1
66 DF475-166 Air Cleaner Assembly 1
66.1 DF475-166.1 Air Filter Element 1
67 DF475-167 Breather Tube 1
68 DF475-168 Fuel Rubber 1
69 DF475-169 Governor Spring 1
70 DF475-170 Clip 1
71 DF475-171 Dipstick 1
72 DF475-172 Bolt M6X30 2
73 DF475-173 Flywheel Assembly 1
74 DF475-174 Starting Motor Assembly 1
75 DF475-175 Adjuster Rocker Arm 2
76 DF475-176 Dustproof Sheet 1
77 DF475-177 Casecover Dowel Pin Ø 8x12 2
