Wen DW5084

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 DW5084-001 Connecting Shaft 1
2 DW5084-002 Semi-circular Key 1
3 DW5084-003 Oil Seal 3
4 DW5084-004 Seal Ring 1
5 DW5084-005 Collar 1
6 DW5084-006
Cross Tapping
Screw M4x12
3
7 DW5084-007
Small Bearing
Cover
1
8 DW5084-008
Deep Groove Ball
Bearing
1
9 DW5084-009 Tapered Gear 1
10 DW5084-010 Seal Ring 1
11 DW5084-011 Bearing 3
12 DW5084-012 Locking Shaft 3
13 DW5084-013 Seal Ring 1
14 6377-015A Gear Box 1
15 DW5084-015 Rotor Coil 1
16 DW5084-016 Wool Cap 1
17 DW5084-017 Middle Cover 1
18 DW5084-018 Anti-Dust Washer 1
19A DW5084-019 Rotor 1
20 DW5084-020 Anti-Dust Ring 1
21 DW5084-021 Ball Bearing 1
22 DW5084-022 Anti-Wind Ring 1
23 DW5084-023 Screw ST4x55 2
24 DW5084-024 Washer 1
25A DW5084-025A Stator 1
26 DW5084-026 Sleeve 1
27 DW5084-027 Logo Label 1
28 DW5084-028 Motor Housing 1
29 DW5084-029 Specification Label 1
30 DW5084-030 Screw M4x20 4
31 DW5084-031 Brush Holder 2
32 DW5084-032 Carbon Brush 2
33 DW5084-033 Screw ST3x10 2
34 DW5084-034 Coil Spring 2
35 DW5084-035
Pressing Block On
Motor Housing
1
No. Part No. Description Qty.
36 DW5084-036 Screw ST4x12 2
37 DW5084-037 Screw ST4x14 40
38 DW5084-038 Back Cover 1
39 DW5084-039 Vibration Damping 2
40 DW5084-040 Rubber Sleeve 2
41 DW5084-041 Screw Pin 2
42 DW5084-042 Flexible Sleeve 1
43 DW5084-043 Cross Screw M4x8 3
44 6377-070
Triangular Sanding
Pad
1
45 DW5084-045 Aluminum Cover 1
46 DW5084-046 Circlip 1
47 DW5084-047
Deep Groove Ball
Bearing
1
48 DW5084-048 Eccentric Shaft 1
49 DW5084-049 Flat Key 1
50 DW5084-050 Eccentric Shaft 1
51 DW5084-051 Circlip 1
52 DW5084-052 Outer Dust Seal 3
53 DW5084-053 Head Footings 3
54 DW5084-054A
Upper Triangular
Head
1
55 DW5084-055
Cross Head Screw
M4*10
3
56 DW5084-056
Cross Screw
ST4x12
12
57 DW5084-057 Seal Ring 4
58 DW5084-058 Washer 4
59 DW5084-059 Triangular Head Base 1
60 DW5084-060 Collar 2
61 DW5084-061 Locking Plate 2
62 DW5084-062
Compression
Spring
2
63 DW5084-063 Locking Pull Knob 2
64 DW5084-064 Pin 1
65 DW5084-065
Compression
Spring
10
66 DW5084-066 Pin Cover 1
67 DW5084-067 Locking Plate 2
68 DW5084-068 Locknut M4 2
