Wen DW5084

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
69 DW5084-069 Circlip 2
70 DW5084-070
Deep Groove Ball
Bearing
2
71 DW5084-071 Front Cover 2
72 DW5084-072 Needle Bearing 2
73 DW5084-073 Steel Ball 2
74 DW5084-074 Gear #2 1
75 DW5084-075 Gear #1 1
76 DW5084-076
Connecting Gear
Shaft
1
77 DW5084-077 Ball Bearing 2
78 DW5084-078 Gasket 2
80 DW5084-079 Bearing Cover 2
81 DW5084-080 Screw M4x12 10
82 DW5084-081 Screw M6x15 1
83 DW5084-082 Ø6 Washer 1
84 DW5062-003
Circular Sanding
Pad
1
85 DW5084-085 Output Shaft 1
87 DW5084-087 Brush Segment 1
88 DW5084-088A Sanding Pad Cover 1
89 DW5084-089 End Gear 1
90 DW5084-090
Connecting Gear
Shaft
1
91 DW5084-091 Pressign Plate 1
92 DW5084-092
Dust Collection
Cover
1
93 DW5084-093
Cross Head Screw
M4x12
2
94 6369-054 Hose Clamp 25-38 1
95 6369-055 350 Hose 1
96 6369-057
Small Rubber
Cover
2
97 6369-062 Left Handle Stand 1
98 6369-059 Ø28 Connector 1
99 6369-060
Plastic Soft Pipe
Ø28
1
100 6369-056 Cable Sleeve 1
101 6369-061 Ellipticle Connector 1
102 6369-083 Aluminium Pipe 1
No. Part No. Description Qty.
103 6369-080 Ø5 Clinch Bolt 2
104 6369-082 Front Hinge 1
105 6369-081 Ø1.2 Sealed Ring 1
106 6369-079 Ø5x45 Pin 1
107 6369-078 Back Hinge 1
108 6369-085 Pin Ø5x30 1
109 6369-086 Pin Ø5x6.8 1
110 6369-066 Cable Plate 2
111 6369-073 Left Main Handle 1
112 6369-075
Cable Pressing
Plate
1
113A 6369-068 Potentiometer 1
114 6369-070 Speed Button 1
115 DW5084-115 Leading Cable 1
116 6369-072 Cable Sleeve 1
117 6369-071 Cable 1
118 6369-093 Switch 1
119 6369-094
Switch Pushing
Lever
1
120 6369-097
Circular Pin
Ø1.5x11.8
1
121 6369-095 Switch Button 1
122 6369-098 Back Screw Nut 2
123 6369-077 Aluminium Pipe 1
124 6369-076 Left Sub-Handle 1
125 6369-090 Latch Pivot 1
126 6369-091 Fixed Plate 1
127 6369-084 Supporting Arm 1
128 6369-087 Sleeve 2
129 6369-089 Spring 1
130 6369-088 Front Latch 1
131 6369-058 Right Handle Stand 1
132 6369-074
Aluminium Pipe
Insert
1
133 6369-092 Aluminium Pipe 1
134 6369-099 Right Main Handle 1
135 6369-092 Right Sub-Handle 1
136 6369-100
Hose Connection
Adapter
1
137 6369-101 Adjustable Ring 1
