Wen GN5600 User Manual

EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 GN5600-001
Phillips Pan Head
Screw, M6x10
4
2 GN5600-002ASM
Control Panel
Assembly
1
3 GN5600-003
Phillips Pan Head
Screw, M5x12
6
4 GN5600-004 Multi-meter 1
5 GN5600-005
NEMA TT-30R 120V
AC 30A RV
Receptacle
1
6 GN5600-006 Engine Switch 1
7 GN5600-007
NEMA L5-30R 120V
AC 30A Receptacle
1
8 GN5600-008
NEMA 5-20R 120V
AC 20A Duplex
Receptacle
1
9 GN5600-009 AC Breaker, 37A 1
10 GN5600-010
Grounding Lug
Assembly
1
11 GN5600-011 Panel 1
12 GN5600-012 Foam Strip 1
14 GN5600-014
Low Oil Indicator
Light
1
15 GN5600-015 AC Breaker, 20A 1
16 GN5600-016
Control Panel
Housing
1
17 GN5600-017 Control Panel Cover 1
18 GN5600-018 Dowel Pin 2
21 GN5600-021 Nut, M8 2
22 GN5600-022 Muffler Gasket 1
23 GN5600-023 Muffler 1
24 GN5600-024 Bolt, M6x16 2
25 GN5600-025
Clamp Hose, ф12
3
26 GN5600-026 Carbon Tank Hose 1 1
27 GN5600-027 Bolt, M6x12 3
28 GN5600-028 Carbon Tank 1
29 GN5600-029 Carbon Tank Hose 2 1
30 GN5600-030 Hose Clamp, 10mm 1
31 GN5600-031 Breather Valve 1
GENERATOR
NO. PART NO. DESCRIPTION QTY.
32 GN5600-032 Fuel Gauge 1
33 GN5600-033 Fuel Tank Filter 1
34 GN5600-034 Fuel Tank Cap 1
35 GN5600-035
Flanged Hex Bolt,
M6x25
4
36 GN5600-036 Flat Washer, 6mm 4
37 GN5600-037
Fuel Tank Vibration
Isolation Sleeve
4
38 GN5600-038
Fuel Tank Vibration
Isolation Pad
4
39 GN5600-039 Fuel Tank 1
40 GN5600-040 Protective Sleeve 1
41 GN5600-041 Combination Clamp 2
42 GN5600-042
Fuel Hose,
ф9.6x440
1
43 GN5600-043 Fuel Valve 1
44 GN5600-044 Frame 1
45 GN5600-045
Flanged Hex Nut,
M8
12
46 GN5600-046 Engine Mount 1
47 GN5600-047
Flanged Hex Bolt,
M6x40
4
48 GN5600-048ASM Foot Bracket 2
49 GN5600-049 Foot Pad 2
50 GN5600-050 Cotter Pin 2
51 GN5600-051 Flat Washer 2
52 GN5600-052 Wheel 2
53 GN5600-053 Wheel Axle 2
54 GN5600-054ASM Engine Assembly 1
55 GN5600-055
Alternator Front
Cover
1
56 GN5600-056
Flanged Hex Bolt,
M8x32
4
57 GN5600-057 Air Filter Bracket 1
58 GN5600-058 Grounding Wire 1
59 GN5600-059
Flanged Hex Bolt,
M6x20
1
60 GN5600-060 Lock Washer, 6mm 1
35
