EXPLODED VIEW & PARTS LIST
ENGINE
NO. PART NO. DESCRIPTION QTY.
55 GN5600-155 Oil Level Sensor 1
56 GN5600-156 Governor Arm 1
57 GN5600-157 Governor Spring 1
58 GN5600-158 Clip 1
59 GN5600-159 Washer 1
60 GN5600-160 Governor Pivot Arm 1
61 GN5600-161
Control Arm
Assembly
1
62 GN5600-162 Governor Gear 1
63 GN5600-163 Crankcase 1
64 GN5600-164
Drain Bolt,
M12-1.5x15
2
65 GN5600-165 Washer, 12mm 2
66 GN5600-166 Ignition Coil 1
NO. PART NO. DESCRIPTION QTY.
67 GN5600-167
Flanged Hex Bolt,
M6x25
2
68 GN5600-168 Flywheel 1
69 GN5600-169 Fan 1
70 GN5600-170 Starter Cup 1
71 GN5600-171
Flanged Hex Nut,
M14-1.5
1
72 GN5600-172 Housing 1
73 GN5600-173 Recoil Starter 1
74 GN5600-174ASM
Recoil Starter
Assembly
1
75 GN5600-175 Clip 1
76 GN5600-176 Cable Clip 2
77 GN5600-177 Oil Alert Module 1
39
