Wen GN5602X User Manual

EXPLODED VIEW & PARTS LIST
GENERATOR
NO. PART NO. DESCRIPTION QTY.
56 GN5600-056
Flanged Hex Bolt,
M8x32
4
57 GN5600-057 Air Filter Bracket 1
58 GN5600-058 Grounding Wire 1
59 GN5600-059
Flanged Hex Bolt,
M6x20
1
60 GN5600-060 Lock Washer, 6mm 1
61 GN5600-061
Flanged Hex Nut,
M6
4
62 GN5600-062 Flat Washer, 6mm 2
63 GN5602X-063 Battery Strap 1
64 GN5602X-064
Battery, 12V 7Ah,
Lead Acid
1
65 GN5602X-065
Battery Quick-
Connector Wiring
Harness
1
66 GN5600-066 Alternator Assembly 1
67 GN5600-067
Carbon Brush
Assembly
1
68 GN5600-068 Terminal Block 1
69 GN5600-069
Flanged Hex Bolt,
M5x6
8
70 GN5600-070 Alternator Bracket 1
71 GN5600-071 Flat Washer, 8.5mm 1
72 GN5600-072
Flanged Hex Bolt,
M5x160
4
NO. PART NO. DESCRIPTION QTY.
73 GN5600-073 Hex Bolt, M8x215 1
74 GN5600-074 Voltage Regulator 1
75 GN5600-075 Alternator Cover 1
76 GN5600-076 Handle Grips 2
77 GN5600-077ASM
Left Handle
Assembly
1
78 GN5600-078
Handle Vibration
Isolation Pad
2
79 GN5600-079 Nut, M8 2
80 GN5600-080 Flat Washer, 8mm 4
81 GN5600-081
Flanged Hex Bolt,
M8x48
2
82 GN5600-082 Pin 2
83 GN5600-083 Plug 2
84 GN5600-084ASM
Right Handle
Assembly
1
85 GN5600-085
Flanged Hex Bolt,
M8x35
2
86 GN5602X-086 Shipping Bracket 1
87 GN5600-087
Flanged Hex Bolt,
M8x16
2
88 GN5600-088 AC Breaker, 30A 1
89 GN5600-089 Spark Arrestor 1
90 GN5600-090
Flanged Hex Bolt,
M6x28
2
91 GN5600-091
Flanged Hex Nut,
M6
4
