EXPLODED VIEW & PARTS LIST
NO. PART NO. DESCRIPTION QTY.
1 GN5600-101
Flanged Hex Bolt,
M6x16
10
2 GN5600-102
Cylinder Head
Cover
1
3 GN5600-103 Oil Filter Block 1
4 GN5600-104
Breather Cover
Plate Gasket
1
5 GN5600-105
Breather Cover
Plate
1
6 GN5600-106
Flanged Hex Bolt,
M5x10
2
7 GN5600-107
Cylinder Head
Cover Gasket
1
8 GN5600-108
Flanged Hex Bolt,
M6x10
5
9 GN5600-109
Cylinder Head
Cowling
1
10 GN5600-110 Lock Washer, 7mm 2
11 GN5600-111
Rocker Arm Shaft
Assembly
2
12 GN5600-112
Rocker Arm
Assembly
2
13 GN5600-113 Push Rod 2
14 GN5600-114 Valve Lifter 2
15 GN5600-115
Flanged Hex Bolt,
M10-1.25x65
4
16 GN5600-116 Valve Rotator 2
17 GN5600-117
Valve Spring
Retainer
2
18 GN5600-118 Valve Spring 2
19 GN5600-119 Valve Set 1
20 GN5600-120 Valve Stem Seal 1
21 GN5600-121
Spark Plug, Torch
F7TC (NGK BP7ES)
1
22 GN5600-122 Stud 2
23 GN5600-123 Cylinder Head 1
24 GN5600-124 Stud 2
25 GN5600-125
Carburetor
Insulator Gasket
1
ENGINE
NO. PART NO. DESCRIPTION QTY.
26 GN5600-126
Carburetor
Insulator
1
27 GN5600-127 Carburetor Gasket 1
28 GN5600-128
Carburetor
Assembly
1
29 GN5600-129 Hose Clamp 1
30 GN5600-130 Fuel Tube 1
31 GN5600-131 Governor Rod 1
32 GN5600-132
Throttle Return
Spring
1
33 GN5600-133 Fuel Tube Sleeve 1
34 GN5600-134 Air Filter Gasket 1
35 GN5600-135 Breather Tube 1
36 GN5600-136
Flanged Hex Nut,
6mm
2
37 GN5600-137 Air Filter Element 1
38 GN5600-138ASM Air Filter Assembly 1
39 GN5600-139
Cylinder Head
Gasket
1
40 GN5600-140 Piston Ring Set 1
41 GN5600-141 Piston 1
42 GN5600-142 Piston Pin 1
43 GN5600-143 Piston Pin Clip 2
44 GN5600-144
Connecting Rod
Assembly
1
45 GN5600-145 Dowel Pin 2
46 GN5600-146
Flanged Hex Bolt,
M8x32
6
47 GN5600-147 Oil Seal 2
48 GN5600-148 Crankcase Cover 1
49 GN5600-149
Oil Dipstick
Assembly
1
50 GN5600-150 Dowel Pin 2
51 GN5600-151
Crankcase Cover
Gasket
1
52 GN5600-152 Camshaft Assembly 1
53 GN5600-153
Crankshaft
Assembly
1
54 GN5600-154 Crankshaft Cowling 1
41
